2 FT-7100M Operating Manual
General
Frequency Range: RX: 108.00 – 180.00 MHz
320 – 480 MHz
810 – 999.990 MHz (Cellular Blocked)
TX: 144 – 146 MHz or 144 – 148 MHz
430 – 440 MHz or 430 – 450 MHz
Channel Steps: 5/10/12.5/15/20/25/50 kHz
Mode of Emission: F3, F2, F1
Antenna Impedance: 50 Ω, unbalanced (Antenna Duplexer built-in)
Frequency Stability: ±5 ppm @ 14° F ~ +140° F (–10 °C ~ +60 °C)
Operating Temperature Range: –4° F ~ +140° F (–20 °C ~ +60 °C)
Supply Voltage: 13.8 VDC (±15%), negative ground
Current Consumption (Approx.): RX: 0.5 A (Squelched)
TX: 11.5 A (VHF), 10.0 A (UHF)
Case Size (WxHxD): 5.8 x1.9 x 6.9 inches (140 x 38 x 166 mm)
(w/o knobs & connectors)
Weight (Approx.): 2.2 lb (1 kg)
Transmitter
Output Power: 50/20/10/5 W (VHF), 35/20/10/5 W (UHF)
Modulation Type: Variable Reactance
Maximum Deviation : ±5 kHz
Spurious Radiation: Better than –60 dB
Modulation Distortion: Less than 3%
Microphone Impedance : 2 kΩ
DATA Jack Impedance: 10 kΩ
Receiver
Circuit Type: Double-conversion superheterodyne
Intermediate Frequencies: 21.7 MHz/450 kHz (VHF), 45.05 MHz/455 kHz (UHF)
Sensitivity (for 12dB SINAD): Better than 0.16 µV
Squelch Sensitivity: 0.1 µV
Image Rejection: 70 dB
Selectivity (–6dB/–60dB): 12 kHz/24 kHz
Maximum AF Output: 2 W @ 8 Ω for 5% THD
AF Output Impedance: 4-16 Ω
Specifications are subject to change without notice, and are guaranteed within the 144
and 430 MHz amateur bands only.
Frequency ranges will vary according to transceiver version; check with your dealer.
SPECIFICATIONS
