23FT-817ND Operating Manual
CLARIFIER
(
RECEIVER INCREMENTAL TUNING
)
The Clarifier (RIT) allows you to set an offset of up to ±9.99 kHz of the receive frequency
relative to your transmit frequency. To achieve a wider offset than this, you may use the
“Split” operating mode, described later.
1. Press the switch momentarily to activate
the Clarifier function.
2. Turn the knob, which allows the re-
ceiver frequency to be varied over a range of
9.99 kHz.
3. When the receiving frequency is higher than
transmit frequency, the “ ” icon will appear at the right of the
frequency display. Similarly, when the receiving frequency is
lower than transmit frequency, the “ ” icon will appear at the
right of the frequency display.
4. When the receiving frequency is equal to transmit frequency
(Clarifier offset is zero) while the Clarifier is activated, the “ ”
icon will appear at the right of the frequency display.
5. To turn the Clarifier off, again press the switch momen-
tarily. When you turn the Clarifier back on, the offset previously
stored will still be applied.
6. To reset the Clarifier offset to zero, turn the Clarifier off, then
turn the knob by any amount. The Clarifier will reset to
zero after the first “step” of the knob.
If you leave the Clarifier on, moving the knob will not cause the offset to be
cancelled.
RECEIVER ACCESSORIES
[
TX<RX
]
[
TX>RX
]
[
TX=RX
]
