44 FT-817ND Operating Manual
QMB CHANNEL
QMB Channel Storage
1. Tune in the desired frequency and set the operating mode and bandwidth. If this is an FM
channel, set up any required CTCSS/DCS and repeater shift configurations.
2. Press and hold in the key until a double “beep” is heard. The second beep provides
audible confirmation that the data has been stored into the QMB memory.
Pressing the
(
A/B
)
key momentarily while in Operating Function Row 3
[
STO,
RCL, PMS
]
will also store a frequency into the QMB register.
QMB Channel Recall
1. Press the key momentarily, then rotate the knob, as needed, until Operating
Function Row 3
[
STO, RCL, PMS
]
appears on the display.
2. Press the
(
RCL
)
key momentarily to recall the QMB memory. “QMB” will appear at
the upper right corner on the LCD.
3. Press the
(
RCL
)
key once more to return to the previous frequency (either a VFO
frequency or a Memory channel).
If you move the knob or knob while in the QMB mode, you can
change frequencies as if you were in a “VFO” mode. You also can change operat-
ing mode by pressing the or key. When this is done, the “MTQMB”
will appear in the display, where “MT” represents “Memory Tuning.” Press the
(
RCL
)
key once more to return to the originally-stored QMB frequency.
MEMORY OPERATION

Yaesu FT-817ND Specifications

General

Output power	1 W
Frequency range	30 - 100000 MHz
Channels quantity	208 channels
Display type	LCD
Product type	Portable CB radio
Product color	Black
Housing material	-
Battery type	AA
Number of batteries supported	8

Weight and Dimensions

Depth	165 mm
Width	135 mm
Height	38 mm
