100 FT-857 Operating Manual
MENU MODE No•021
[
CLAR DIAL SEL
]
Function: Defines the SELECT knob to be used for setting of the clarifier offset frequency.
Available Values: SEL, MAIN (Selector/Main Dial Knobs)
Default: SEL
MENU MODE No-022
[
CW AUTO MODE
]
Function: Selects whether the KEY jack shall be “Enabled” or “Disabled” while using the
SSB/FM modes.
Available Values: ON/OFF
Default: OFF
OFF:The KEY jack is enabled on the CW mode only.
ON: The KEY jack is enabled on all modes (SSB mode: A1, FM mode: F2). Thus, on SSB,
you can respond to a station asking for a CW QSO without having to change your FT-
857’s Mode selection, if Menu #022 is set to “ON.”
MENU MODE No•023
[
CW BFO
]
Function: Sets the CW carrier oscillator injection side on the CW mode.
Available Values: USB/LSB/AUTO
Default: USB
USB: Injects the CW carrier oscillator on the USB side
LSB: Injects the CW carrier oscillator on the LSB side
AUTO: Injects the CW carrier oscillator on the LSB side while operating on the 10 MHz
band and below, USB side while operate on the 10 MHz band and up.
MENU MODE No-024
[
CW DELAY
]
Function: Sets the receiver recovery time during pseudo-VOX CW semi-break-in opera-
tion.
Available Values: FULL/30 ~ 3000 msec
Default: 250 msec
The recovery time may be adjusted in steps of 10 msec. A longer delay may be preferable if
you pause frequently while sending.
MENU MODE No•025
[
CW KEY REV
]
Function: Sets the keyer paddle’s wiring configuration.
Available Values: NORMAL/REVERSE
Default: NORMAL
NORMAL: Keyer paddle polarity is normal. The “tip” plug connection produces dots, and
the “ring” plug connection produces dashes.
REVERSE: Keyer paddle polarity is inverted. The “tip” paddle produces dashes, and the
“ring” paddle produces dots.
MENU OPERATION
