46 FT-857 Operating Manual
AUTOMATIC POWER-OFF FEATURE
The APO feature helps conserve battery life by automatically turning the transceiver off
after a user-defined period of time within which there has been no dial or key activity. The
available selections for the time before power-off are 1 ~ 6 hours, as well as “APO Off.” The
default condition for the APO is OFF, and here is the procedure for activating it:
1. Press and hold in the
[
FUNC
]
key for one second to enter the Menu mode.
2. Rotate the SELECT knob to recall Menu Mode No-007
[
APO TIME
]
.
3. Rotate the DIAL knob to select the desired time period after which the radio will auto-
matically shut down.
4. Press and hold in the
[
FUNC
]
key for one second to save the new setting and exit to
normal operation.
Once you have programmed a time interval, the APO countdown timer will start whenever
some front panel action (tuning, transmission, etc.) is completed.
When the APO is activated, the “ ” icon will appear at the center top on the LCD. If there
is no action by you within the time interval programmed, the microprocessor will shut down
the radio automatically.
Just press and hold in the POWER switch for one second to turn the transceiver back on
after an APO shutdown, as usual.
The APO feature will be disabled while using the Beacon or ARTS features, even
if the APO feature is set to “ON.”
RECEIVER ACCESSORIES

Yaesu FT-857D Specifications

General

Modes	SSB, CW, AM, FM, WFM
Impedance	50 Ohms, unbalanced
Supply Voltage	13.8 V DC ±15%
Frequency Range	420-470 MHz
Power Output	100 W (HF/50 MHz), 50 W (144 MHz), 20 W (430 MHz)
Current Consumption	22 A (maximum)
Dimensions	155 x 52 x 233 mm (6.1" x 2.0" x 9.2")
Weight	2.1 kg
Channels	200
Receiver Sensitivity	0.2 μV (SSB/CW)
