FT-99
1
InsTrucTIon Manual (WIrEs-X EdITIon)
Page 10
coMMunIcaTIng usIng WIrEs-X
ConneCTing To a node or room on The inTerneT in analog mode
When connecting to a local node which is an analog station, use the optional DTMF microphone “MH-36E8J”.
1. Connect the optional DTMF microphone “MH-36E8J” to the
transceiver.
2. Set the communication mode to FM.
After pressing the
MODE
button, touch “FM” on the screen.
3. Tune to the frequency of the local node you want to connect to.
4. While pressing
[PTT]
on the microphone, press the buttons (
[#]
,
[0]
to
[9]
) on the microphone to transmit the access code.
eXample:
[#]
→
[2]
→
[0]
→
[5]
→
[1]
→
[1]
5. Release
[PTT]
, and keep the transceiver in reception mode for about
ten seconds.
When the connection is successfully established, you will be able to
hear audio.
Tip:
The ID information of the connection destination does not appear.
disConneCTing from The node or room you are ConneCTed To in analog mode
1. While pressing
[PTT]
on the microphone, press the buttons on the
microphone to transmit #99999 (disconnection command).
Disconnects the node or room.
Tip:
You can disconnect from some specic nodes just by transmitting
[*]
.
CommuniCaTing WiTh oThers
1. Press
[PTT]
on the microphone.
The transceiver switches to transmit mode.
2. Speak into the microphone.
Speak into the microphone in your normal speaking voice while
keeping it about 5 cm away from your mouth. Do not continuously
transmit over an extended period of time to reduce the risk of
overheating, malfunction, or injury.
CauTion:
Maximum continuous TX: three minutes
3. Release
[PTT]
.
The transceiver switches to receive mode.
To Next Page
