INSTRUMENT AND CONTROL FUNCTIONS
3-12
3
ECA00038
CAUTION:
@
Do not use the starter (choke) for
more than 3 minutes as the exhaust
pipe may discolor from excessive
heat. In addition, extended use of
the starter (choke) will cause after-
burning. If this occurs, turn off the
starter (choke).
@
EAU01890
Seats
Rider seat
To remove the rider seat
Lift up the rear corners of the rider seat
as shown, remove the bolts, and then
pull the seat off.
To install the rider seat
Insert the projection on the front of the
rider seat into the seat holder as
shown, place the seat in the original
position, and then install the bolts.
1. Bolt (× 2) 1. Projection
2. Seat holder
E_5mt.book Page 12 Thursday, October 5, 2000 3:24 PM
