Matching the front and rear suspension settings
Use this table as a guide to match the suspension and damping adjustments of the front fork and shock absorber assembly
according to various load conditions.
CI-05E
EC000015
CAUTION:
@
Never attempt to turn an adjusting mechanism beyond the maximum or minimum settings.
@
Load condition Front fork adjustment Shock absorber assembly adjustment
Spring preload
Compression
damping force
Rebound
damping force
Spring preload
Compression
damping force
Rebound
damping force
Rider only 1–8 1–10 1–9 1–7 4–12 3–20
With passenger 1–8 1–10 1–9 4–9 1–8 3–7
