2-11
E
403022
403041
403016
EMD47010
TILT SUPPORT KNOB
2
To keep the outboard motor in the tilted-
up position, push the tilt support knob
under the swivel bracket.
2
3
5
EMD48010
TILT SUPPORT BAR
3/5
The tilt support bar keeps the outboard
motor in the tilted up position.
6A1-9-1L 2 4/20/01 12:00 PM Page 12

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha 2A and is the answer not in the manual?

Yamaha 2A Specifications

General IconGeneral
Engine Type2-Stroke
Mixing Ratio50:1
Starting SystemManual
Full Throttle RPM Range4500 - 5500 rpm
Fuel TypeGasoline
Oil Type2-stroke oil
Gear Ratio2.08:1
Gear ShiftF
Shaft LengthS
