GB
2-6
EMC46010
STARTER BUTTON (for Tiller control
model)
When you push the starter button, the
electric starter motor cranks the engine to
start it.
EMC64010*
THROTTLE FRICTION KNOB/SCREW
(for Tiller control model)
A friction device in the tiller handle pro-
vides resistance to movement of the
throttle grip. This is adjustable for opera-
tor preference.
To increase the resistance:
Turn the adjusting screw/bolt clockwise.
To decrease the resistance:
Turn the adjusting screw/bolt counter-
clockwise.
When constant speed is desired, tighten
the adjusting screw/bolt to maintain the
desired throttle setting.
w
Do not overtighten the friction adjusting
screw/bolt. If there is too much resis-
tance, it may be difficult to move the
throttle grip, which could result in an
accident.
EMC60010
TILLER HANDLE (for Tiller control
model)
Moving the tiller handle sideways to
adjust the steering direction.
