Yamaha CD-S2100 - Wiring Diagrams - Overall Assembly; Overall Assembly Wiring Connections

Under side view
Wire length exposed on the upper side EXCLUDING housing
100 mm
(3-7/8")
110 mm
(4-3/8")
RED
BLUE
Flexible flat cable
to DIGITAL (CB405)
Letter side
Letter side
40 mm
(1-5/8")
25 mm
(1")
130 mm
(5-1/8")
to FRONT (3) (CB910)
Flexible flat cable
to FRONT (3)
(CB909)
90˚ mountain fold
90˚ valley fold
Letter side
Letter side
to Loader mechanism unit
25 mm
(1")
40 mm
(1-5/8")
10 mm (3/8")
12 mm (1/2")
20 mm
(3/4")
Route the twisted wires
(avoid from entering area)
ø18 mm
30 mm
(1-1/8")
Top view Bottom view
Front panel (View A)
DIGITAL
FRONT (1)
FRONT (2)
FRONT (8)
AC IN
AUDIO
FRONT (3)
FRONT (4)
FRONT (5)
FRONT (6)
RED
BLUE
Route the wire between FRAME/FRONT and FRONT PANEL
Dress the wire
by cord clamp
Put the wire
into SLOT HOLE
Put the wire
into SLOT HOLE
12x50
12x25
Hold the FFC
by style-pin
Hold the housing
by cord clamp
Hold the housing
by cord clamp
Cable under
frane trans
Letter side
to Loader mechanism unit
CB909
CB910
CB908
W904
CB912
W905
CB911
CB913
CB1
CB410CB902
BLACK
RED
GRAY
BROWN
CB405
CB402 CB404
CB901
W902
to FRONT (3)
(CB910)
to DIGITAL (CB406)
to FRONT (3)
(CB910)
RED
BLUE
BLACK
GRAY
BROWN
WHITE
45˚
CB408
CB401
CB406
CB407
to Module board
(CN211)
to Module board
(CN210)
W903
W901
View A
LOADER MECHANISM UNIT
POWER
TRANSFORMER
POWER
TRANSFORMER
to FRONT (3)
(CB908)
to FRONT (3)
(CB908)
ABCDEFGH I J
1
2
3
4
5
6
7
48
CD-S2100
■ WIRING DIAGRAMS
• OVERALL ASSEMBLY
