Yamaha F200 User Manual

Instruments and indicators
51
Stop the engine immediately if the buzzer
sounds and the low oil pressure-alert indica-
tor blinks. Check the engine oil level and re-
plenish oil if necessary. If the alert device has
activated while the appropriate engine oil lev-
el is maintained, consult your Yamaha dealer.
NOTICE
ECM01602
Do not continue to run the engine if the
low oil pressure alert device has activated.
Serious engine damage will occur.
1. Low oil pressure-alert indicator
1
ZMU08417
U6DV37E0.book Page 51 Monday, December 10, 2018 4:07 PM
©2020 Yamaha Motor Corporation

Yamaha F200 Specifications

General

Prop Shaft Horsepower	200 hp
Full Throttle RPM Range	5000 - 6000 rpm
Compression Ratio	10.3:1
Gear Ratio	1.86:1
Starting System	Electric
Steering	Remote
Trim & Tilt	Power Trim & Tilt
Displacement	2785cc
Bore x Stroke	96.0mm x 96.2mm
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	50 Amp
Weight	227 kg (500 lbs)
Shaft Length	L: 20 in, X: 25 in
