4-10
6X4 MULTI-FUNCTION TILLER HANDLE
MULTI-FUNCTION TILLER HANDLE
CONTENTS (FOR OTHERS)
The tiller handle kit is not prepared f
or other market.
Regarding the tiller handle comp
onent parts informat
ion, see th
e applicable 200
9
model parts cata-
log.
TILLER HANDLE GROMMET DESCRIPTION
T
roll RPM switch
(Fuel injected F50-F100)
LED indicators
* Overheat w
ar
ning
* Oil w
ar
ning
PTT switch (T
op)
LED indicator lead
10-pin main harness
T
roll RPM s
witch
Throttle cable
Shift cable
115
117
Table of Contents
Table of Contents
5
Top Cover Pictograph Description
