DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
SQUARE STYLE GAUGE RIGGING KIT FOR US & CANADA
TRIPLE KIT 2 (TACH, TACH, TACH, SPEED, FUEL MGT) w/o Triple RCL Box
Kit P/N: 6Y8-WE83S-90-00
ROUND STYLE GAUGE RIGGING KIT FOR US & CANADA
SINGLE KIT 1 (TACH)
Kit P/N: 6Y8-WE83R-60-00
Part No. Part Name Q’ty Remarks
60V-8A4L1-11 Speed sensor kit 1 Refer to kit contents
6Y8-82553-01 Main bus wire, 1 ft 1
6Y8-82521-51 Pigtail bus wire, 12 ft 3
6Y8-81920-01 Multi-hub 3 With resistor cap, GRY
6Y8-82582-01 2-P cap, RED 2 For waterproof
6Y8-82582-11 2-P cap, WHT 1 For waterproof
6Y8-8350T-01 SQR tachometer 3
6Y8-8350S-01 SQR speedometer 1
6Y8-8350F-01 SQR fuel management gauge 1
6Y8-8356N-01 Fuel tank & GPS wire 1
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
6X5-82570-01 Triple-switch panel 1
6K1-8258A-40 Main-harness 10-P, 26 ft 1
61B-8258A-01 Main-harness 10-P, 32 ft 2
6Y8-2819U-X0 Quick operation guide 1 Laminated card
6Y8-2819U-00 Operation manual 1
Part No. Part Name Q’ty Remarks
6Y8-82521-51 Pigtail bus wire, 12 ft 1
6Y8-81920-11 Single-hub 1 With resistor
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-83553-01 PWR supply wire, 8 ft 1 With 10 amps fuse
6Y8-82521-11 Pigtail bus wire, 2 ft 1
6Y8-8350T-11 RND tachometer 1
6Y8-82582-11 4-P cap, WHT 2 For waterproof
6Y8-2819V-00 Operation manual 1
6Y8-2819K-R1 Quick installation guide 1
6Y8-2819V-X0 Quick operation guide 1 Laminated card
