3-26
REMOTE CONTROL ATTACHMENT KIT
If the specified tightening torque for the bolts and nuts is not mentioned in the figure, use standard
torque as follows.
General torque table
N•m kgf•m lb•ft
M5 5 0.5 4
M6 8 0.8 6
M8 18 1.8 13
Part No. Applicable model
6G1-48501-50 6C (6), 8C (8)
Part No. Applicable model
6AH-48501-00
F9.9H, F13.5B, F15C (F15),
F20B (F20)
Part No. Applicable model
60R-G8501-00
F6A (F6), F8C (F8), FT8D (T8)
F9.9F (F9.9), FT9.9G (T9.9)
Part No. Applicable model
63V-48501-00 9.9F (9.9), 15F (15)
To be continued.
