PERIODIC MAINTENANCE AND MINOR REPAIR
6-15
6
6. Check the final gear case for oil
leakage. If oil is leaking, check for
the cause.
EAU20070
Coolant
The coolant level should be checked
before each ride. In addition, the cool-
ant must be changed at the intervals
specified in the periodic maintenance
and lubrication chart.
EAU39511
To check the coolant level
The coolant level should be checked as
follows before each ride. In addition,
the coolant must be changed at the in-
tervals specified in the periodic mainte-
nance and lubrication chart.
1. Place the vehicle on the center-
stand.
NOTE:
● The coolant level must be checked
on a cold engine since the level
varies with engine temperature.
● Make sure that the vehicle is posi-
tioned straight up when checking
the coolant level. A slight tilt to the
side can result in a false reading.
2. Check the coolant level in the cool-
ant reservoir.
NOTE:
The coolant should be between the
minimum and maximum level marks.
3. If the coolant is at or below the
minimum level mark, remove the
reservoir cap.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Maximum level mark
2. Minimum level mark
U2D211E0.book Page 15 Friday, January 5, 2007 3:56 PM

Yamaha FJR 2007 Specifications

General

Compression Ratio	10.8:1
Fuel System	Fuel Injection
Final Drive	Shaft
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Engine Type	Liquid-cooled inline 4-cylinder, DOHC, 16 valves
Bore x Stroke	79.0mm x 58.0 mm
Transmission	5-speed
Rear Suspension	Single shock; adjustable preload and rebound damping
Front Brakes	Dual 320mm discs; ABS
Rear Brakes	282mm disc; ABS
Wheelbase	60.8 in
Seat Height	31.7 inches
Fuel Capacity	6.6 gallons
Ignition	TCI (Transistor Controlled Ignition)
Width	29.5 in
Length	87.8 in
