2-24
E
Analog speedometer
The analog speedometer shows the
watercraft speed against water.
The large inner numbers on the meter
show the watercraft speed in miles per hour
(mph) and the small outer numbers show
the speed in kilometers per hour (km/h)
when the speedometer function is selected.
Analog tachometer
The analog tachometer shows the engine
speed (r/min).
The small outer numbers on the meter
show the engine speed when the tachome-
ter function is selected.
EJU22260
“SPEED” indicator light
The “SPEED” indicator light 1 comes on
when the analog speedometer is selected.
The “SPEED” indicator light blinks three
times in the following instances:
●
The analog speedometer/tachometer is
switched to the speedometer function.
●
The display units of the multifunction
meter are switched to miles from kilome-
ters.
●
Miles are selected as the display units
when the multifunction meter starts oper-
ating.
E_F1X-10.book Page 24 Friday, August 5, 2005 10:34 AM
