3-3
E
EJU17990
Engine oil
Use a combination of the recommended
SAE and API oil classifications shown in the
chart below.
@
Use only 4-stroke engine oil.
@
EJU18002
Filling the fuel tank
@
Be careful when refueling. Avoid getting
water or other contaminants in the fuel
tank. Contaminated fuel can cause poor
running or engine damage.
@
1. Remove the rear and front seats. (See
pages 2-5 and 2-6 for seat removal and
installation procedures.)
2. Open the fuel tank filler cap, and slowly
add fuel to the fuel tank.
3. Stop filling when the fuel level reaches
approximately 50 mm (2 in) from the top
of the fuel tank as indicated a in the
illustration.
Fuel tank capacity:
70.0 L (18.5 US gal, 15.5 Imp gal)
E_F1X-10.book Page 3 Friday, August 5, 2005 10:34 AM
