EAS00007
HOW TO USE THIS MANUAL
This manual is intended as a handy, easy-to-read reference book for the mechanic. Comprehensive
explanations of all installation, removal, disassembly, assembly, repair and check procedures are laid
out with the individual steps in sequential order.
1
The manual is divided into chapters. An abbreviation and symbol in the upper right corner of each
page indicate the current chapter. Refer to “SYMBOLS” on the following page.
2
Each chapter is divided into sections. The current section title is shown at the top of each page,
except in Chapter 3 (“Periodic Checks and Adjustments”), where the sub-section title(-s) appears.
(In Chapter 3, “Periodic Checks and Adjustments”, the sub-section title appears at the top of each
page, instead of the section title.)
3
Sub-section titles appear in smaller print than the section title.
4
To help identify parts and clarify procedure steps, there are exploded diagrams at the start of each
removal and disassembly section.
5
Numbers are given in the order of the jobs in the exploded diagram. A circled number indicates a
disassembly step.
6
Symbols indicate parts to be lubricated or replaced (see “SYMBOLS”).
7
A job instruction chart accompanies the exploded diagram, providing the order of jobs, names of
parts, notes in jobs, etc.
8
Jobs requiring more information (such as special tools and technical data) are described sequen-
tially.

Yamaha FZS1000 2003 Specifications

General

Compression Ratio	11.4:1
Transmission	6-speed
Final Drive	Chain
Frame	Aluminum Deltabox
Front Tire	120/70-ZR17
Width	750 mm
Maximum Power	143 hp @ 10, 000 rpm
Maximum Torque	106 Nm @ 7, 500 rpm
Ignition	Digital
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Rear Brakes	245mm disc, 1-piston caliper
Rear Tire	180/55 ZR17
Length	2, 140 mm
Height	1, 210 mm
Seat Height	820 mm
Wheelbase	1, 450 mm
Fuel Capacity	21 liters
Dry Weight	208 kg
Engine Type	998cc, liquid-cooled, 4-stroke, DOHC, 20 valves, inline-4
Fuel System	Fuel Injection
