Yamaha HTR-5830 Service Manual

RX-V357/HTR-5830
15
RX-V357/HTR-5830
7
D
S
P
P
.C
.B
.
N
o
te
:
W
h
e
n
a
s
s
e
m
b
lin
g
th
e
D
S
P
P
.C
.B
., b
e
c
a
re
fu
l n
o
t to
b
e
n
d
th
e
p
in
o
f th
e
c
o
n
n
e
c
to
rs
(C
B
2
4
7
a
n
d
C
B
2
4
9
).
S
u
p
p
o
rt / D
S
P
C
B
8
0
3
Fig. 2
6
4
5
5
Fig. 3
3. Removal of MAIN (3) ~ MAIN (5), FUNCTION
(3), FUNCTION (6) P.C.B.s and Tuner
a. Remove CB242, CB391 and CB701. (Fig. 2)
b. Remove 9 screws (4). (Fig. 3)
c. Remove MAIN (3), MAIN (5) P.C.B.s. and the
Tuner. (Fig. 2)
d. Remove 18 screws (5). (Fig. 3)
e. Remove 3 screws (6). (Fig. 3)
f. Remove Cord Stopper. (Fig. 2)
g. Remove Rear Panel. (Fig. 2)
h. Remove MAIN (4), FUNCTION (3) and
FUNCTION (6) P.C.B.s. (Fig. 2)
Fig. 4
4. Removal of DSP P.C.B.
a. Remove 1 screw (7 ). (Fig. 4)
b. Remove CB803. (Fig. 4)
c. Remove the DSP P.C.B. with the Support/DSP. (Fig. 4)
C
B
2
4
2
FUNCTION (6)
P. C . B .
FUNCTION (3) P.C.B.
CB391
CB701
MAIN (3) P.C.B.
TUNER
MAIN (4) P.C.B.
MAIN (5) P.C.B.
REAR PANEL
CORD STOPPER
