67
RX-V357/HTR-5830
■ MECHANICAL PARTS
* 1‑1 WE545000 P.C.B.ASS'Y FUNCTION UCTKA
* 1‑1 WE545100 P.C.B.ASS'Y FUNCTION R
* 1‑1 WE545200 P.C.B.ASS'Y FUNCTION BGE
* 1‑1 WE857100 P.C.B.ASS'Y FUNCTION (YEM) L
1‑2 MF114180 FLEXIBLEFLATCABLE 14P180mmP=1.25
* 1‑4 WE066700 FRONTPANELASS'Y V357GD
* 1‑4 WE233600 FRONTPANELASS'Y V357BL
* 1‑4 WE066800 FRONTPANELASS'Y V357SI
* 1‑4 WE067200 FRONTPANELASS'Y 5830GD
* 1‑4 WE067100 FRONTPANELASS'Y 5830BL
* 1‑4 WE067300 FRONTPANELASS'Y 5830SI UCRTKA
* 1‑4 WE762000 FRONTPANELASS'Y 5830SI BGE
1‑5 WC411600 BUTTONCASE350 V357GD,5830GD
1‑5 WC411500 BUTTONCASE350 V357BL
1‑5 WC411800 BUTTONCASE350 5730BL
1‑5 WC411700 BUTTONCASE350 V357SI,5830SI
1‑6 WC411900 BUTTON/RDS350 BGE
1‑13 WC910400 SHEET,WINDOW V357,5830 UCRKAL
1‑13 WC412800 SHEET,WINDOW V357,5830 T
* 1‑13 WE813800 SHEET,WINDOW V357 BGE
* 1‑13 WE814900 SHEET,WINDOW 5830 GE
* 1‑25 WE774800 BINDHEADP‑TIGHTSCREW 3x8MFZN2W3
* 2‑1 WD044200 P.C.B.ASS'Y DSP (YEM) UCRKABGEL
* 2‑1 WE741100 P.C.B.ASS'Y DSP T
2‑7 MF111070 FLEXIBLEFLATCABLE 11P70mmP=1.25
2‑20 WC656000 SUPPORT/TR5P
* 2‑103 WE774600 SCREWIC 3x18MFZN2W3
2‑104 VT669300 PWHEADB‑TIGHTSCREW 3x8‑8MFC2
* 5 WE544300 P.C.B.ASS'Y MAIN UC
* 5 WE544400 P.C.B.ASS'Y MAIN R
* 5 WE544500 P.C.B.ASS'Y MAIN T
* 5 WE544600 P.C.B.ASS'Y MAIN K
* 5 WE544700 P.C.B.ASS'Y MAIN A
* 5 WE544800 P.C.B.ASS'Y MAIN BGE
* 5 WE856900 P.C.B.ASS'Y MAIN (YEM) L
12 WB424000 AM/FMTUNER ENG06709Q UCRTL
12 WB424100 AM/FMTUNER ENG07711Q KABGE
s 15 X6311A00 POWERTRANSFORMER UC
* s 15 X5278B00 POWERTRANSFORMER RL
* s 15 X5279B00 POWERTRANSFORMER TK
* s 15 X5280B00 POWERTRANSFORMER A
s 15 X5275B00 POWERTRANSFORMER BGE
s 16 WB120500 POWERCABLE 2m UC
s 16 WC992700 POWERCABLE 2m R
s 16 WB120600 POWERCABLE 2m T
s 16 WC753000 POWERCABLE 2m K
s 16 WC743700 POWERCABLE 2m A
s 16 WB212200 POWERCABLE 2m B
s 16 WB212300 POWERCABLE 2m GE
s 16 VN363600 POWERCABLE 2m (YEM) L
17 V2438700 CORDSTOPPER 10P1
23 MF113140 FLEXIBLEFLATCABLE 13P140mmP=1.25
✻ New Parts
Schm
Ref. PARTNO. Description Remarks Markets
* 101 WE065200 TOPCOVER GD T
* 101 WE538700 TOPCOVER GD(YEM) L
* 101 WE065000 TOPCOVER BL
* 101 WE538900 TOPCOVER SI(YEM) UCRKABGEL
* 101 WE065100 TOPCOVER SI T
* 103 WE065600 REARPANEL V357 UC
* 103 WE065700 REARPANEL V357 R
* 103 WE065800 REARPANEL V357 TK
* 103 WE233500 REARPANEL V357 A
* 103 WE066000 REARPANEL V357 BGE
* 103 WE065900 REARPANEL V357(YEM) L
* 103 WE066100 REARPANEL 5830 UC
* 103 WE066200 REARPANEL 5830 R
* 103 WE066300 REARPANEL 5830 TK
* 103 WE066400 REARPANEL 5830 A
* 103 WE066500 REARPANEL 5830 BGE
109 WA796100 SUPPORT/PCB
120 WA790600 LEG(GD) D60/H21 GD T
120 V0042500 LEG(GD) D60/H21 GD(YEM) L
120 VS025000 LEG(HS) D60/H21 V357BL,SI
120 WA790700 LEG(BL) D60/H21 5830BL
* 121 WE064300 KNOBD48 VOLUME GD
* 121 WE064200 KNOBD48 VOLUME BL
* 121 WE064400 KNOBD48 VOLUME SI
150 VU590000 BINDINGTIE CBTD001B
151 WB870100 DAMPER
152 WC879000 DAMPER
* 160 WE774100 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2B3
* 163 WE774300 BINDHEADB‑TIGHTSCREW 3x8MFZN2W3
* 164 WE774000 BINDHEADSCREW 3x6MFZN2W3 UCR
167 VT669300 PWHEADB‑TIGHTSCREW 3x8‑8MFC2
* 168 WE774600 SCREWIC 3x18MFZN2W3
* 170 WE774700 BINDHEADS‑TIGHTSCREW 4x10MFZN2W3
171 VD069600 PWHEADS‑TIGHTSCREW 4x8‑10MFNI33 GD,SI
171 VH313200 PWHEADS‑TIGHTSCREW 4x8‑10MFNI3BL BL
* 172 WE200400 DISHHEADB‑TIGHTSCREW 3x6MFNI33 GD,SI
* 172 WE200500 DISHHEADB‑TIGHTSCREW 3x6MFNI3BL BL
ACCESSORIES
200 WA220300 REMOTECONTROL RAV300 RRC4001‑1001LC UCRTKAL
200‑1 AAX46580 BATTERYCOVER 103RRC‑244‑01G UCRTKAL
201 WA617700 REMOTECONTROL RAV16 RC1112921/00 BGE
201‑1 AAX49660 BATTERYCOVER 313922422451 BGE
202 V6267000 INDOORFMANTENNA 1.4m1pc (YEM) UCRL
202 WB212500 INDOORFMANTENNA 1.4m1pc T
202 WB212400 INDOORFMANTENNA 1.4m1pc KABGE
203 VR248500 AMLOOPANTENNA 1.0m1pc (YEM) UCRKABGEL
203 WB212600 AMLOOPANTENNA 1.0m1pc T
BATTERY,MANGANESEDRY R6CP2pcs
✻ New Parts
Schm
Ref. PARTNO. Description Remarks Markets
