MIDI Implementation Chart
86
■ Effect map
* If the received value does not contain an effect type in the TYPE LSB, the LSB will be directed to TYPE 0.
* The numbers in parentheses in front of the Effect Type names correspond to the number indicated in the display..
* By using an external sequencer, which is capable of editing and transmitting the system exclusive messages and parameter changes, you can select the Reverb, Chorus and DSP
effect types which are not accessible from the PSR-GX76 panel itself. When one of the effects is selected by the external sequencer, “ - ” will be shown on the display.
● REVERB
● CHORUS
● DSP
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000 No Effect
001 (1)Hall1 (2)Hall2
002 Room (3)Room1 (4)Room2
003 Stage (5)Stage1 (6)Stage2
004 Plate (7)Plate1 (8)Plate2
005...127 No Effect
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000...064 No Effect
065 Chorus Chorus2
066 Celeste Chorus1
067 Flanger Flanger1 Flanger2
068...127 No Effect
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000 No Effect
001 (1)Hall1 (2)Hall2
002 Room (3)Room1 (4)Room2
003 Stage (5)Stage1 (6)Stage2
004 Plate (7)Plate1 (8)Plate2
005 Delay L,C,R (26)Delay L,C,R
006 (27)Delay L,R
007 (28)Echo
008 (29)Cross Delay
009
(9)Early Reflection1 (10)Early Reflection2
010 (11)Gate Reverb
011 (12)Reverse Gate
012...019 No Effect
020 (30)Karaoke
021...064 No Effect
065 Chorus (14)Chorus2
066 Celeste (13)Chorus1
067 Flanger
(15)Flanger1
(16)Flanger2
068 Symphonic (17)Symphonic
069 Rotary Speaker
(19)Rotary Speaker1
070 Tremolo (21)Tremolo1
071 Auto Pan (24)Auto Pan
(20)Rotary Speaker2
(22)Tremolo2
(23)Guitar Tremolo
072 (18)Phaser
073 Distortion
074 (33)Overdrive
075
(34)Amp Simulation
(31)Distortion Hard
(32)Distortion Soft
076 (36)3Band EQ
(35)EQ Telephone
077 (37)2Band EQ
078 Auto Wah (25)Auto Wah
079...127 No Effect
