3-4
E
EJU01316
Filling the oil tank
WARNING
@
●
Do not add gasoline to the oil tank.
Fire or explosion could result.
●
Oil in the bilge is a serious fire hazard.
Wipe up any spilled oil immediately.
@
@
Do not allow the oil tank to become com-
pletely empty. If the oil tank becomes
empty the oil injection pump must be
bled to ensure proper oil flow, otherwise
engine damage may occur. If bleeding of
the oil pump is necessary, have a
Yamaha dealer bleed it.
@
1. Remove the rear and front seats to
access the oil filler cap. (See pages 2-4
and 2-5 for seat removal and installation
procedures.)
2. Open the oil tank filler cap, and very
slowly add engine oil to the oil tank.
3. Stop pouring when the oil just reaches
the bottom of the filler tube.
N
TE:
@
●
The rear and front seats must be removed
in order to watch the oil level in the oil
tank while adding oil.
●
Be careful not to spill oil or overfill the
tank.
●
Do not fill into the filler tube because oil
could overflow.
@
Oil tank capacity:
5.5 L (1.5 US gal, 1.2 Imp gal)
UGU513.book Page 4 Tuesday, June 10, 2003 12:21 PM
To Next Page
