3-13
E
EJU20620
Quick Shift Trim System (QSTS)
Check the shift lock lever and the QSTS
selector for proper operation.
1. Operate the shift lock lever and the
QSTS selector to check that they oper-
ate properly.
2. Check that the QSTS selector locks
when the lever is released.
3. Check that the selector turns smoothly
when the lever is squeezed and held in
place.
4. Check that the angle of the jet thrust
nozzle changes when the selector is
shifted from neutral to bow up or bow
down.
If the mechanism does not work properly,
have a Yamaha dealer service it.
UGU513.book Page 13 Tuesday, June 10, 2003 12:21 PM
