AUDIO SECTION
• Minimum RMS Output Power for Front, Center, Surround,
Surround back
[U.S.A. and Canada models]
1 kHz, 0.9% THD, 8 Ω ........................................................... 90 W
[Other models]
1 kHz, 0.9% THD, 6 Ω ........................................................... 90 W
• Dynamic Power (IHF)
[U.S.A. and Canada models]
Front Speakers 8/6/4/2 Ω ...................................95/110/130/150 W
[Other models]
Front Speakers 6/4/2 Ω ...........................................100/110/125 W
• Maximum Useful Output Power (JEITA) [Australia, General and
Asia models]
1 kHz, 10% THD, 6 Ω ..........................................................115 W
• Maximum Output Power [Russia and Asia models]
1 kHz, 0.7% THD, 4 Ω ......................................................... 105 W
• Dynamic Headroom [U.S.A. and Canada models]
8 Ω ...................................................................................... 0.23 dB
• IEC Output Power [Russia and Asia models]
Front Speakers 1 kHz, 0.9% THD, 6 Ω ..................................90 W
• Input Sensitivity/Input Impedance
PHONO [Russia, Australia, General and Asia models]
.............................................................................. 3.5 mV/47 kΩ
AV5, etc. ................................................................. 200 mV/47 kΩ
MULTI CH INPUT................................................. 200 mV/47 kΩ
• Maximum Input Voltage
PHONO (1 kHz, 0.1% THD)
[Russia, Australia, General and Asia models]
............................................................................. 60 mV or more
AV5, etc. (1 kHz, 0.5% THD) .................................. 2.0 V or more
• Rated Output Voltage/Output Impedance
AUDIO OUT ......................................................... 200 mV/1.2 kΩ
PRE OUT....................................................................1.0 V/1.2 kΩ
SUBWOOFER (2ch Stereo & Front: Small)
.................................................................................1.0 V/1.2 kΩ
ZONE2 OUT ......................................................... 200 mV/1.2 kΩ
• Headphone Jack Rated Output/Impedance
AV5, etc. (1 kHz, 50 mV, 8 Ω) ............................... 100 mV/470 Ω
• Frequency Response
AV5 to FRONT.................................. 10 Hz to 100 kHz, +0/–3 dB
• RIAA Equalization Deviation
[Russia, Australia, General and Asia models]
PHONO ..........................................................................0 ± 0.5 dB
• Total Harmonic Distortion
PHONO to AUDIO OUT
[Russia, Australia, General and Asia models]
(20 Hz to 20 kHz, 1 V) ........................................... 0.02% or less
AV5, etc. to FRONT, Pure Direct
[U.S.A. and Canada models]
(1 kHz, 50 W, 8 Ω) ................................................. 0.06% or less
[Other models]
(1 kHz, 50 W, 6 Ω) ................................................. 0.06% or less
• Signal to Noise Ratio (IHF-A Network)
PHONO Input Shorted (5.0 mV to AUDIO OUT)
[General model]
.............................................................................. 80 dB or more
PHONO Input Shorted (5.0 mV to AUDIO OUT)
[Russia, Australia and Asia models]
.............................................................................. 86 dB or more
AV5, etc. Input Shorted (250 mV to Front Speakers)
............................................................................ 100 dB or more
• Residual Noise (IHF-A Network)
Front Speakers ......................................................... 150 µV or less
• Channel Separation (1 kHz/10 kHz)
PHONO (Input Shorted)
[Russia, Australia, General and Asia models]
....................................................................60 dB/55 dB or more
AV5, etc. (5.1 kΩ shortened) .........................60 dB/45 dB or more
• Volume Control.................................... MUTE / –80 dB to +16.5 dB
• Tone Control (Front Speakers)
BASS Boost/Cut....................................................±10 dB at 50 Hz
BASS Turnover Frequency ..................................................350 Hz
TREBLE Boost/Cut ............................................±10 dB at 20 kHz
TREBLE Turnover Frequency ............................................3.5 kHz
• Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz)
H.P.F. (Front, Center, Surround, Surround back: Small)
......................................................................................12 dB/oct.
L.P.F. (Subwoofer) ..........................................................24 dB/oct.
VIDEO SECTION
• Video Signal Type (Gray Back)
[U.S.A., Canada and General models] .................................. NTSC
[Other models] ......................................................................... PAL
• Video Signal Type (Video Conversion)............................NTSC/PAL
• Signal Level
Composite ...................................................................1 Vp-p/75 Ω
S-video [Russia models]
........................................1 Vp-p/75 Ω (Y), 0.286 Vp-p/75 Ω (C)
Component ........................................................... 1 Vp-p/75 Ω (Y)
• Maximum Input Level (Video Conversion Off)
............................................................................. 1.5 Vp-p or more
• Signal to Noise Ratio .................................................. 50 dB or more
• Frequency Response [MONITOR OUT]
Component (Video Conversion Off)
.................................................................5 Hz to 60 MHz, –3 dB
FM SECTION
• Tuning Range
[U.S.A. and Canada models]............................. 87.5 to 107.9 MHz
[Asia and General models]..........87.5/87.50 to 108.0/108.00 MHz
[Other models] ..............................................87.50 to 108.00 MHz
• 50 dB Quieting Sensitivity (IHF)
Mono ...................................................................3.0 µV (20.8 dBf)
• Signal to Noise Ratio (IHF)
Mono/Stereo................................................................74 dB/69 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo......................................................................0.3/0.3%
• Antenna Input (unbalanced)....................................................... 75 Ω
AM SECTION
• Tuning Range
[U.S.A. and Canada models]................................ 530 to 1710 kHz
[Asia and General models]................... 530/531 to 1710/1611 kHz
[Other models] ..................................................... 531 to 1611 kHz
GENERAL
• Power Supply
[U.S.A. and Canada models]................................AC 120 V, 60 Hz
[General model] ................ AC 110/120/220/230–240 V, 50/60 Hz
[Australia model] .................................................AC 240 V, 50 Hz
[Russia model] .....................................................AC 230 V, 50 Hz
[Asia model].....................................AC 220/230–240 V, 50/60 Hz
• Power Consumption
[U.S.A. and Canada models]................................... 270 W/320 VA
[Other models] ..................................................................... 280 W
• Standby Power Consumption
Standby through off.................................................... 0.2 W or less
Standby through on ....................................................... 3 W or less
• Maximum Power Consumption
[Asia and General models]................................................... 490 W
• Dimensions (W x H x D) .................................. 435 x 151 x 364 mm
(17-1/8 x 6 x 14-3/8 in)
• Weight ...................................................................... 8.5 kg (18.7 lbs)
* Specifications are subject to change without notice.
