TIGHTENING TORQUES
Part to be tightened Thread size
Tightening torque
Nm m · kg ft · lb
Engine:
Spark plug M12 18 1.8 13
Engine oil drain bolt M35 32 3.2 23
Chassis:
Steering knuckle and nut M14 70 7.0 50
Front wheel and front wheel hub M10 45 4.5 32
Bearing holder and frame M42 40 4.0 29
Steering knuckle and knuckle arm M10 38 3.8 27
Steering knuckle and front brake caliper M8 28 2.8 20
Front brake disc and front wheel hub M8 28 2.8 20
Steering knuckle and ball joint M10 25 2.5 18
Tie-rod and knuckle arm M10 25 2.5 18
Tie-rod and steering shaft M10 25 2.5 18
Tie-rod locknut M10 15 1.5 11
Steering shaft and frame M10 35 3.5 25
Steering shaft bearing holder and frame M8 23 2.3 17
Handlebar holder and steering shaft M8 20 2.0 14
Front brake master cylinder and holder M6 7 0.7 5.1
Clutch and parking brake lever assembly and hold-
er
M5 4 0.4 2.9
Lower arm and frame M10 45 4.5 32
Upper arm and frame M10 45 4.5 32
Front shock absorber and frame M10 48 4.8 35
Front shock absorber and lower arm M10 48 4.8 35
Frame and engine stay M8 33 3.3 24
Engine and engine stay M8 33 3.3 24
Frame and engine M10 65 6.5 47
Pivot shaft and frame M16 85 8.5 61
Rear shock absorber and frame M12 80 8.0 58
Relay arm and swingarm M12 66 6.6 48
Rear shock absorber and relay arm M12 66 6.6 48
Connecting rod and relay arm M12 66 6.6 48
Connecting rod and frame M12 66 6.6 48
Spring preload adjusting locknut (rear shock ab-
sorber)
M44 42 4.2 30
Footrest and frame M10 65 6.5 47
Rear brake disc and bracket M8 28 2.8 20
Rear hub and rear brake caliper M8 34 3.4 24
Rear wheel and rear wheel hub M10 45 4.5 32
Rear axle ring nut M33 160 16.0 115
Rear axle and rear wheel hub M16 120 12.0 85
Rear wheel hub and swingarm (upper) M12 120 12.0 85
