Yamaha yz450f 2012 Service Manual

4-27
CLUTCH
CLUTCH
REMOVING THE CLUTCH
Order Part name Q'ty Remarks
Drain the engine oil.
Refer to "CHANGING THE ENGINE OIL"
section in the CHAPTER 3.
Brake pedal Refer to "ENGINE REMOVAL" section.
Clutch cable Disconnect at engine side.
1 Clutch cover 1
2 Gasket 1
3 Clutch spring 6
4 Pressure plate 1
5 Push rod 1 1
6 Circlip 1
7 Washer 1
8 Bearing 1
9Ball 1
10 Push rod 2 1
11 Clutch plate 7
12 Friction plate 8
13 Nut (clutch boss) 1 Refer to removal section.

Yamaha yz450f 2012 Specifications

General

Bore x Stroke	97.0mm x 60.8mm
Compression Ratio	12.5:1
Fuel Delivery	Fuel Injection
Transmission	5-speed
Final Drive	Chain
Tires Front	80/100-21
Tires Rear	120/80-19
Wheelbase	58.7 in
Trail	4.6 in
Fuel Capacity	1.6 gal
Wet Weight	245 lb
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Ignition	TCI
Suspension Front	Telescopic fork, 12.2 in travel
Suspension Rear	Swingarm, 12.4 in travel
Brakes Front	Hydraulic single disc brake, 250mm
Brakes Rear	Single disc, 245 mm
