FUEL PUMP SYSTEM
FUEL PUMP SYSTEM
INSPECTION STEPS
If the fuel pump is not operating normally, perform the following procedures in the order given.
• Remove the following parts before inspection.
1. Seat
2. Side cover (right/left)
3. Fuel tank
• Use the following special tools in this inspection.
Check engine stop switch. No good → Replace.
OK ↓
Checking the couplers and leads connections No good → Repair or replace.
OK ↓
Check the fuel pump.(Checking the fuel pump
body)
No good →
Replace the fuel pump assembly.
OK ↓
Replace the ECU.
Pocket tester:
YU-03112-C/90890-03112
Test harness S-pressure sensor (3P):
YU-03207/90890-03207

Yamaha yz450f 2012 Specifications

General

Bore x Stroke	97.0mm x 60.8mm
Compression Ratio	12.5:1
Fuel Delivery	Fuel Injection
Transmission	5-speed
Final Drive	Chain
Tires Front	80/100-21
Tires Rear	120/80-19
Wheelbase	58.7 in
Trail	4.6 in
Fuel Capacity	1.6 gal
Wet Weight	245 lb
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Ignition	TCI
Suspension Front	Telescopic fork, 12.2 in travel
Suspension Rear	Swingarm, 12.4 in travel
Brakes Front	Hydraulic single disc brake, 250mm
Brakes Rear	Single disc, 245 mm
