Yamato DX302 User Manual

33
10. Specifications
Model
DX302 DX402 DX602
40℃～300℃ 40℃～280℃
Temperature
control range
At no load and at an ambient temperature of 23
℃
Temperature
control precision
±1℃（setting: 300℃, exhaust port fully opened）
Temperature
distribution
precision
±10℃
(setting: 300, exhaust port fully opened)
±10℃
(setting: 280, exhaust port
fully opened)
Performance
Temperature rise
time
Approx. 45 minutes
(Room temperature～
300℃)
Approx. 60 minutes
(Room temperature～
300℃)
Approx. 80 minutes
(Room temperature～
280℃)
Exhaust port Rotation damper with opening rate of 20% when closed
Iron-chrome heater
Mechanism
Heater
0.9 kW 1.36 kW
Control system PID control of heater output with a micro computer
Setting system Digital setting using up/down keys
Operation mode
Fixed temperature operation, quick auto stop operation
Auto stop operation, auto start operation
Sensor K thermocouple
Control assembly
Auxiliary
functions
Lock function, power outa
g
e compensation function, calibration offset function
Controller
Self diagnostic
function
Temperature sensor error, memory error, auto overheat prevention,
measured temperature error
Safety device
Protection device
ELB with an over current protector,
Standalone overheat prevention device (Thermostat)
Outer dimensions
(mm)
(w x d x h)
400×440×630 550×540×730 700×640×830
Inner dimensions
(mm)
(w x d x h)
300×310×300 450×410×400 600×510×500
Internal volume 28ℓ 74ℓ 153ℓ
Weight Approx. 23kg Approx. 38kg Approx. 56kg
Standard
Power supply
(i50/60Hz)
100V 9.5A 100V 14A 100V 14A
Included items
Shelf board x 2 (withstand load approx. 15kg /each), operating
instructions, warranty card
*Performance values are for the VAC100 power supply.
*Operating environmental temperature range for this device is 5℃～35℃.
