BEFORE YOU OPERATE
16 SD60 Operation Manual
LUBRICATING OIL
The selection of lubricating oil is very important. If an inappropriate oil is used, or an oil
change is neglected, it may result in damage and reduce the life of the Sail-Drive. When
selecting a lubricating oil, use one of the following:
1. Lubricating oil type: API Service Categories CD or higher, SAE Viscosity 15W-40
2. Lubricating oil quantity: Figure 1
3. Loosen dipstick (1, Figure 1) by turning the grip counterclockwise.
4. Wipe dipstick with a clean and dustfree cloth.
5. Insert dipstick do not screw. Remove dipstick and check lubricating oil level:
Lubricating oil level has to be between minimum and maximum marks on the dipstick.
6. Check O-ring (2, Figure 1) for damage, replace if necessary.
7. Insert the dipstick and lock it by turning the grip clockwise.
Figure 1
Quantity (l)
Standard (S) 2.8
with extension (L) 3
1–Dipstick 2–O-ring
Housing surface
Oil level max.
Dipstick
1
2
Oil level min.
050440-00EN01
