PERIODIC MAINTENANCE
SD60 Operation Manual 23
MAINTENANCE PROCEDURES
Oil Level Check
1. Check the oil level by removing the
dipstick.
Wipe the dipstick with a clean, lint-free
cloth.
Figure 1
2. Insert the dipstick so that it rests on top
of the threads into the case.
Remove the dipstick and check the
lubricating oil level on the dipstick. The
lubricating oil level must be between
the marks of minimum and maximum
on the dipstick. Add oil as necessary.
Figure 2
1 – Dipstick
2–Maximum
3 – Minimum
4 – Upper edge of threaded hole
Figure 3
