PERIODIC MAINTENANCE
28 SD60 Operation Manual
4. Remove the propeller sleeve.
Figure 16
Installing Propeller
1. Assemble the propeller shaft thrust
bearing sleeve. Install chamfered side
away from propeller.
Figure 17
2. Put some anti-corrosion grease on the
grooves of the propeller shaft.
Figure 18
050911-01X00
050912-01X00
Description Employment
Antifouling grease Propeller shaft splines
Special lubricant Propeller shaft splines
Marine lubricant with
teflon
Propeller shaft splines
050912-01X00
