YOKOGAWA RAMC User Manual

<7. HART-COMMUNICATION>
7- 8
IM 01R01B02-00E-E 12th edition October 01, 2014 -00
All Rights Reserved. Copyright © 2003, Rota Yokogawa
Error description :
Status Type Current value Bars
blinking
Error on
Display
Self Test HHT275 Reset Function by Clear
all
Status group 1 RAM error error 3.6 mA / > 21 mA -------- 00000001 check ON/OFF NO (RAMC to service !) no
ADC error error 3.6 mA / > 21 mA -------- 00000010 check ON/OFF NO (RAMC to service !) no ADC-EE error error 3.6 mA / > 21 mA -------- 00000100 check ON/OFF NO (RAMC to service !) no CAL-EE error error 3.6 mA / > 21 mA -------- 00001000 check ON/OFF Insert new EEPROM no Totalizer false warn no change -------- 00010000 check ON/OFF Reset Counter yes Flow overrun warn no change -------- 00100000 no check ON/OFF NO (active during overow) yes ADJ error 2 warn no change -------- 01000000 no check ON/OFF NO (RAMC to service !) yes FB time elapsed error 3.6 mA / > 21 mA -------- 10000000 no check ON/OFF NO (RAMC to service !) yes
Status group 2 Temp over limit warn no change -------- 00000001 no check ON/OFF Switch off Temp Log Funct./Clear Values yes
Max ow 1 active warn no change -------- 00000010 no check ON/OFF Clear Values at Flow Log Function yes Max ow 2 active warn no change -------- 00000100 no check ON/OFF Clear Values at Flow Log Function yes FB autoz active warn no change -------- 00001000 no check ON/OFF NO (active during autozero) yes Power fail warning warn no change 1) 00010000 no check ON/OFF Clear warning at operation monitor yes Operate timer error warn no change -------- 00100000 no check ON/OFF NO (RAMC to service !) yes Mancal active warn no change 2) 01000000 no check ON/OFF Switch off manual calibration yes
