Assembly instructions
Prepare your work area -
It is important you assemble the product in a clean and uncluttered space.
Work with a friend -
We recommend you have someone assist you with the assembly as
some of the components are quite heavy.
Open the carton -
Check any warnings on the carton and make sure you have it the right
way up.
Unpack the carton -
Remove all the parts and lay them out on the floor.
Make sure you have the following parts:
A
x 4
ALLEN HEAD BOLT
(M8 X 45 X 20MM)
E
x 1
T-SHAPE SPANNER
C
x 4
SPRING WASHER
(Ø8)
D
x 4
FLAT WASHER
(Ø8)
B
x 4
MACHINE SCREW
(ST4 X 20)
BASE FRAME COVER
LEFT & RIGHT
SAFETY KEY
LUBRICATION OIL
MAIN FRAME
F
x 1
CROSS SPANNER
