York ECO2 YPAL 050 User Manual

102
JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
User Interface Control Center
ADDRESS
NUMBER
DESCRIPTION UNITS OF ADJUSTMENT
RANGE OF
ADJUSTMENT
CURRENT
SETTING
36 OUTSIDE AIR HUMIDITY SENSOR INSTALLED PARAMETER BIT 0 = OFF, 1 = ON OFF
37 ECONOMIZER OUTSIDE AIR ENTHALPY SETPOINT BTUS PER POUND 10 - 50 27
38 RETURN AIR HUMIDITY SENSOR INSTALLED PARAMETER BIT 0 = OFF, 1 = ON OFF
39
ECONOMIZER OUTSIDE AIR TEMP ENABLE
SETPOINT
DEGREES F 40º - 80º 55º
40 DEMAND VENTILATION (IAQ) ENABLED PARAMETER BIT 0 = OFF, 1 = ON OFF
41 IAQ SENSOR RANGE PARTS PER MILLION 0 - 5000 PPM 2000
42 IAQ SETPOINT PARTS PER MILLION 0 - 5000 PPM 1000
43 POWER EXHAUST INSTALLED PARAMETER BIT 0 = OFF, 1 = ON ON
44 MODULATING POWER EXHAUST INSTALLED PARAMETER BIT 0 = OFF, 1 = ON OFF
45 EXHAUST VFD INSTALLED PARAMETER BIT 0 = OFF, 1 = ON OFF
46
EXHAUST DAMPER POSITION FOR EXHAUST FAN
TO TURN ON (MODULATING ONLY)
PERCENT OF ECONOMIZER
POSITION
0 - 100% 80%
47
EXHAUST DAMPER POSITION FOR EXHAUST FAN
TO TURN OFF
PERCENT OF ECONOMIZER
POSITION
0 - 100% 20%
48
ECONOMIZER DAMPER POSITION FOR EXHAUST
FAN TO TURN ON (NON-MODULATING ONLY)
PERCENT OF ECONOMIZER
POSITION
0 - 100% 60%
49
ECONOMIZER DAMPER POSITION FOR EXHAUST
FAN TO TURN OFF (MODULATING ONLY)
PERCENT OF ECONOMIZER
POSITION
0 - 100% 20%
50 APS DATA
0 = CLOSED,
1 = OPEN
0 = CLOSED,
1 = OPEN
OPEN
51 DIRTY FILTER SWITCH INSTALLED PARAMETER BIT 0 = OFF, 1 = ON OFF
52 DIRTY FILTER SWITCH DATA
0 = CLOSED,
1 = OPEN
0 = OPEN,
1 = CLOSED
OPEN
53 COOLING MODE OPERATION ENABLE PARAMETER BIT 0 = OFF, 1 = ON ON
54 HEATING MODE ENABLED FOR OPERATION PARAMETER BIT 0 = OFF, 1 = ON ON
55
CONTINUOUS INDOOR FAN OPERATION WITH
SENSOR
PARAMETER BIT 0 = OFF, 1 = ON ON
56 SPACE TEMPERATURE OFFSET RANGE DEGREES F -5º F - 5º F 0º F
57 METRIC OPERATION PARAMETER BIT 0 = OFF, 1 = ON OFF
58 THIRD PARTY BAS ECONOMIZER ENABLED PARAMETER BIT 0 = OFF, 1 = ON OFF
59 YEAR YEAR (BCD) 00 - 99 4
60 MONTH MONTH 1 - 12 1
61 DAY OF MONTH DAY OF MONTH 1 - 31 1
62 DAY OF WEEK DAY OF WEEK 1 - 7 1
63 HOUR HOURS 0 - 23 0
64 MINUTE MINUTES 0 - 59 0
65 SUPPLY AIR TEMP DEGREES F -40º - 180º 0
66 RETURN AIR TEMP DEGREES F -40º - 180º 0
67 OUTSIDE AIR TEMP DEGREES F -40º - 180º 0
68 SPACE TEMP DEGREES F -40º - 180º 0
69 OUTSIDE AIR HUMIDITY HUMIDITY 0% - 100% 0
70 RETURN AIR HUMIDITY HUMIDITY 0% - 100% 0
71 OCCUPIED INPUT ENABLE PARAMETER BIT 0 = OFF, 1 = ON OFF
TABLE - 6-1 - PARAMETER POINTS LIST (CONT.)
Continued on next page
