EZ Zone/Meridian
Upgrade 31
036-21423-001 Rev. A (0602)
Upgrade Parts List Summary
All the standard components that are required or avail-
able for the Meridian to EZ Zone upgrades are summa-
rized below. See the upgrade examples on pages 8
through 13 of this manual for the parts lists that are
required for your specific application.
For other Meridian products such as CV Unit Control-
lers, Lighting Panel Controllers etc., please see pages
14 & 15 or consult the factory to see if these are avail-
able for your specific application.
Part No Description
2ZSM004702924
OE392-01-SYSM
System Manager
(Used on Plus Systems)
Includes: System Manager Only.
2ZZC004708124
OE751
EZ Zone To Auto-Zone Basic Upgrade Kit
Includes:
Zone Manager Board w/ Mounting Screws, Plastic Standoff Kit for
Zone Manager, Return Air Sensor, Upgrade Label, Installation Instructions.
2ZZC004708324
OE753
EZ Zone To Auto-Zone Plus Upgrade Kit
Includes: Zone Manager Board w/ Mounting Screws, Plastic Standoff Kit for
Zone Manager, MiniLink w/ Mounting Hardware, Return Air Sensor, 3 Way
Display/Keypad Connector cable, Upgrade Label, Installation Instructions.
2ZDS004700224
OE231
Duct Temperature Sensor
(10kohm with 12” Probe, used for Return or Supply Air Sensor)
Includes: Duct Temperature Sensor, 2 Wire with 12” Long Probe.
2ZOT004704424
OE250
Outside Air Temperature Sensor
(10kohm)
Includes: Temperature Sensor Mounted in Weatherproof Handy Box.
2ZEM004703424
OE419-04
Remote Data Link
(
Modem- External
-14,400 Baud )
Includes: Modem and 120/9 VAC Power Supply.
2ZCP004703124
OE361-04
CommLink II
(Used on Basic & Plus Systems )
Includes: CommLink II, Power Supply & Cables for Connection to Computer and
Remote Link are Included.
2ZZC004708224
OE752
Replacement EPROM Chip
Contains Auto-Zone software to replace EZ Zone software in Zone Controller
Includes: EPROM Chip
2ZZC004708424
OE755
Modem Linc Central To CommLink II Upgrade Kit
Includes: ComLink II EPROM Upgrade Chip, Upgrade Label
2ZZC004708524
OE754
Master Interface Board To MiniLink Upgrade Kit
Includes: MiniLink EPROM Upgrade Chip, Upgrade Label
2ZXX004708124
EC101600-3
Blank Enclosure Cover
Used to replace EZ Zone Master Controller Cover when Keypad & Display are
not Desired. Includes: Metal Enclosure Cover Only
2ZVS004700024
ZoneView AZ Software
Windows Based Software for Accessing System using a PC
Includes: 3.5” Floppy Installation Diskettes and Operations Manual.
To Next Page
