TABLE 3:
Physical and Electrical Data
Models F*FP 024 030 036 040
Blower - Diameter x Width 10 x 6 10 x 8 10 x 8 10 x 8
Motor
HP 1/4 1/3 1/2 1/3
Nominal RPM 1075 1075 1075 1075
Voltage 208/230
Amps
Full Load (208/230) 1.6/1.4 (50 Hz:2.1) 2.5 / 2.2 3.3/2.9 (50 Hz:2.3) 2.5 / 2.2
Locked Rotor (208/230) 3.3 / 2.9 6.2 / 5.5 7.4 / 6.5 6.2 / 5.5
Filter
1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 20 x 20 x 1 20 x 20 x 1
Permanent Type Kit 1PF0601BK 1PF0601BK 1PF0602BK 1PF0602BK
Shipping / Operating Weight (lbs.) 98 / 93 105 / 100 115 / 109 121 / 115
Models F*FP 042 045 048 060
Blower - Diameter x Width 10x8 10x10 11x10 11x10
Motor
HP 3/4 1/3 1.0 1.0
Nominal RPM 1130 925 1050 1050
Voltage 208/230 230
Amps
Full Load (208/230) 4.4/3.8 3.0/2.7 7.6 7.6
Locked Rotor (208/230) 11.9/10.3 4.8/4.1 NA NA
Filter
1
Type DISPOSABLE OR PERMANENT
Size 20 x 20 x 1 22 x 20 x 1 22 x 20 x 1 22 x 20 x 1
Permanent Type Kit 1PF0602BK 1PF0603BK 1PF0603BK 1PF0603BK
Shipping / Operating Weight (lbs.) 121/115 150/144 153/147 160/154
1. Field Supplied
TABLE 4:
Electrical Data - Cooling Only (50 & 60 Hz)
Models F*FP
Total Motor Amps Minimum Circuit Ampacity
Max. O.C.P.
1
Amps/Type
Minimum Wire
Size A.W.G.
60 Hertz 60 Hertz
208V 240V 208V 240V
024 1.6 1.5 2.0 1.8 15 14
030 2.5 2.3 3.2 2.8 15 14
036 3.3 3.0 4.2 3.7 15 14
040 2.5 2.3 3.2 2.8 15 14
042 4.4 4.0 5.5 4.8 15 14
045 3.1 2.6 3.9 3.4 15 14
048 7.6 7.6 9.5 9.5 15 14
060 7.6 7.6 9.5 9.5 15 14
1. OCP = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
TABLE 5:
Conversion Table
KW & MBH Conversions - for Total Power Input Requirement
FOR
208V
OPERATION MULTIPLY
240V
TABULATED KW & MBH BY
.751
230V 240V .918
220V 240V .840
