York F4FP024H06T2A User Manual

404912-UIM-A-0508
Johnson Controls Unitary Products 9
* May be 0 (no breaker) or 1 (with breaker).
TABLE 6: Electrical Data - 1 Ø - 208/230-1-60
1
Models F*FP
Heater*
Model
Max. Static
& Min. CFM
Total Heat
2
KW Staging
3
KW MBH W1 Only W2 Only W1 + W2
Static Tap 208V 240V 208V 240V 208V 240V 208V 240V 208V 240V
024
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
030
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B HI 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
036
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16501906B
4
0.5 High 13.2 17.6 45.1 60.1 2.8 3.8 10.4 13.8 13.2 17.6
040
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B High 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
042
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Low 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
045
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Med 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B High 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
048
2HK*6500506B
0.5
Med Low
3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Med Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Med Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med Low 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16502006B Med Low 15.0 20.0 51.2 68.3 3.8 5.0 11.3 10.0 15.0 20.0
2HK16502506B Med Low 18.8 25.0 64.2 85.3 3.8 5.0 11.3 15.0 18.8 25.0
060
2HK*6500506B
0.5
Med
3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Med 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Med 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16502006B Med 15.0 20.0 51.2 68.3 3.8 5.0 7.5 10.0 15.0 20.0
2HK16502506B Med 18.8 25.0 64.2 85.3 3.8 5.0 11.3 15.0 18.8 25.0
1. Heat amps shown at 240V represents maximum heater rating.
2. See conversion Table 5.
3. If first stage heat or 66 is connected to W1, otherwise refer to this table.
4. 2HK16501906B only applies to F4FP036 model.
