13
FORM 160.47-NOM3
YORK INTERNATIONAL
FIG. 3 – STANDARD NEOPRENE VIBRATION ISOLATOR PAD MOUNTS
1
LD02942
LD02944
LD02943
OPERATING WEIGHT (Lbs. / Kgs.) DETAIL
UP TO 16,365 / 7,423 A
16,636 / 7,546 to 28,835 / 13,080 B
28,836 / 13,080 to 53,530 / 24,281 C
