32 YORK INTERNATIONAL
FIG. 16 – OIL SEPARATOR SCHEMATIC
LD04302
First Stage of Oil Separation
Reduction in Velocity
Second Stage of Oil Separation
Extended Surface Area
Third Stage of Oil Separation
Coaleser Element
Oil Out
Oil & Refrigerant
Gas to Eductor
6
1
2
1
3
4
5
1
1. Sight Glass
2. Oil Level Switch
3. Filter Pressure Transducer and Isolation Valve
4. Oil Charging Valve
5. Oil Heater
6. Discharge Temperature Sensor
Operation
