246824-YTG-G-1208
Johnson Controls Unitary Products 23
115°F 125°F
1625
77 75.4 7.9 27.1 25.6 18.6 - - - 68.5 8.9 27.1 21.3 16.5 - - -
72 68.0 7.6 43.7 36.6 29.6 22.5 - - 61.5 8.4 40.8 34.0 27.2 20.4 - -
67 60.5 7.3 60.2 47.6 40.6 33.5 26.5 - 54.6 8.0 54.6 44.8 38.0 31.2 24.4 -
62 56.4 7.2 56.4 56.4 45.8 38.8 31.8 24.7 50.6 8.0 50.6 50.6 40.7 33.9 27.1 20.3
1950
77 77.4 7.9 37.5 29.1 20.6 - - - 70.2 8.9 38.3 26.7 18.4 - - -
72 69.7 7.6 49.7 41.2 32.8 24.3 - - 63.0 8.5 47.1 38.7 30.3 21.9 - -
67 62.1 7.3 61.9 53.4 45.0 36.5 28.0 - 55.9 8.0 55.9 50.7 42.3 33.9 25.5 -
62 57.8 7.3 57.8 57.8 50.8 42.4 33.9 25.4 51.8 8.0 51.8 51.8 45.4 37.0 28.6 20.3
57 61.0 7.2 61.0 59.0 50.6 42.1 33.6 25.2 55.4 7.9 55.4 53.3 44.9 36.5 28.2 19.8
2275
77 79.3 7.9 47.9 32.5 22.6 - - - 71.9 9.0 49.4 32.1 20.2 - - -
72 71.5 7.6 55.8 45.9 36.0 26.1 - - 64.5 8.5 53.3 43.4 33.4 23.5 - -
67 63.7 7.3 63.6 59.3 49.4 39.5 29.6 - 57.2 8.0 57.2 56.5 46.6 36.7 26.7 -
62 59.3 7.3 59.3 59.3 55.8 45.9 36.0 26.2 53.1 8.0 53.1 53.1 50.0 40.1 30.2 20.2
57 62.6 7.2 62.6 61.6 55.5 45.6 35.8 25.9 56.7 8.0 56.7 55.7 49.5 39.6 29.6 19.7
2600
77 81.3 8.0 58.4 35.9 24.6 - - - 73.5 9.0 60.5 37.5 22.1 - - -
72 73.3 7.6 61.8 50.5 39.2 27.9 - - 66.0 8.5 59.5 48.0 36.5 25.0 - -
67 65.3 7.3 65.3 65.1 53.8 42.5 31.2 - 58.5 8.0 58.5 58.5 50.9 39.4 27.9 -
62 60.8 7.3 60.8 60.8 60.8 49.5 38.2 26.9 54.3 8.0 54.3 54.3 54.3 43.2 31.7 20.2
57 64.1 7.3 64.1 64.1 60.5 49.2 37.9 26.6 58.1 8.0 58.1 58.1 54.1 42.6 31.1 19.6
2925
72 74.2 7.6 66.7 54.3 42.0 29.7 - - 66.5 8.5 64.0 51.5 39.1 26.6 - -
67 66.1 7.3 66.1 66.0 57.6 45.3 33.0 - 59.0 8.0 59.0 59.0 54.5 42.0 29.6 -
62 61.5 7.3 61.5 61.5 61.5 49.2 36.9 24.6 54.7 8.0 54.7 54.7 54.7 42.4 30.0 17.5
57 64.9 7.3 64.9 64.9 63.1 50.8 38.4 26.1 58.5 8.0 58.5 58.5 56.5 44.1 31.6 19.2
3250
72 75.1 7.6 71.5 58.2 44.8 31.5 - - 67.0 8.5 67.0 55.1 41.6 28.2 - -
67 66.9 7.3 66.9 66.9 61.5 48.1 34.8 - 59.4 8.0 59.4 59.4 58.1 44.7 31.2 -
62 62.3 7.3 62.3 62.3 62.3 48.9 35.6 22.2 55.1 8.0 55.1 55.1 55.1 41.7 28.3 14.9
57 65.7 7.3 65.7 65.7 65.7 52.4 39.0 25.7 58.9 8.0 58.9 58.9 58.9 45.5 32.1 18.7
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZH078 (6.5 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
