30 Johnson Controls Unitary Products
ZH150 (12.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
3125
77 187.0 9.5 73.2 60.2 47.2 - - - 182.7 10.6 74.6 61.2 47.8 - - -
72 176.3 9.5 98.5 85.5 72.4 59.4 - - 169.9 10.5 98.6 85.2 71.9 58.5 - -
67 165.5 9.4 123.7 110.7 97.7 84.7 71.7 - 157.2 10.4 122.7 109.3 95.9 82.5 69.1 -
62 149.3 9.2 149.3 143.1 119.8 106.8 93.8 80.8 142.6 10.2 142.6 139.6 118.5 105.1 91.7 78.3
3750
77 193.7 9.6 82.5 67.3 52.2 - - - 188.6 10.7 83.1 67.8 52.4 - - -
72 182.5 9.6 110.4 95.2 80.1 64.9 - - 175.5 10.6 109.5 94.1 78.8 63.5 - -
67 171.4 9.5 138.3 123.1 108.0 92.8 77.7 - 162.3 10.5 135.8 120.5 105.2 89.9 74.5 -
62 154.5 9.3 154.5 150.5 132.4 117.3 102.1 87.0 147.3 10.3 147.3 145.3 129.9 114.6 99.3 84.0
57 155.4 9.2 155.4 155.4 138.2 123.1 107.9 92.8 148.3 10.3 148.3 148.3 133.2 117.9 102.5 87.2
4375
77 200.3 9.7 91.7 74.4 57.2 - - - 194.6 10.8 91.6 74.3 57.1 - - -
72 188.8 9.7 122.3 105.0 87.7 70.4 - - 181.0 10.7 120.3 103.0 85.8 68.5 - -
67 177.2 9.6 152.8 135.5 118.2 101.0 83.7 - 167.5 10.6 149.0 131.7 114.5 97.2 80.0 -
62 159.8 9.3 159.8 157.8 145.0 127.7 110.5 93.2 152.0 10.4 152.0 151.0 141.4 124.2 106.9 89.6
57 160.7 9.3 160.7 160.7 151.3 134.0 116.8 99.5 152.9 10.4 152.9 152.9 144.9 127.7 110.4 93.2
5000
77 207.0 9.8 101.0 81.6 62.2 - - - 200.6 10.9 100.1 80.9 61.7 - - -
72 195.1 9.8 134.2 114.7 95.3 75.9 - - 186.6 10.8 131.1 111.9 92.7 73.5 - -
67 183.1 9.7 167.3 147.9 128.5 109.1 89.7 - 172.6 10.7 162.2 143.0 123.8 104.6 85.4 -
62 165.1 9.4 165.1 165.1 157.6 138.2 118.8 99.4 156.6 10.5 156.6 156.6 152.9 133.7 114.5 95.3
57 166.0 9.4 166.0 166.0 164.4 145.0 125.6 106.2 157.6 10.5 157.6 157.6 156.7 137.5 118.3 99.1
5625
72 203.6 9.7 143.3 122.5 101.8 81.1 - - 193.3 10.8 140.6 120.0 99.4 78.7 - -
67 191.1 9.6 183.2 158.0 137.2 116.5 95.8 - 178.9 10.7 173.6 153.2 132.6 112.0 91.3 -
62 172.4 9.4 172.4 172.4 168.6 147.9 127.1 106.4 162.3 10.5 162.3 162.3 160.4 139.8 119.2 98.5
57 173.3 9.3 173.3 173.3 172.5 151.8 131.0 110.3 163.3 10.4 163.3 163.3 162.9 142.2 121.6 101.0
6250
72 212.2 9.7 152.4 130.3 108.2 86.2 - - 200.1 10.8 150.1 128.0 106.0 83.9 - -
67 199.1 9.6 199.1 168.0 145.9 123.9 101.8 - 185.1 10.7 185.1 163.5 141.4 119.3 97.3 -
62 179.6 9.4 179.6 179.6 179.6 157.5 135.5 113.4 168.0 10.4 168.0 168.0 168.0 145.9 123.8 101.8
57 180.6 9.3 180.6 180.6 180.6 158.5 136.5 114.4 169.0 10.4 169.0 169.0 169.0 147.0 124.9 102.8
95°F 105°F
3125
77 178.3 11.7 76.0 62.2 48.4 - - - 167.8 13.1 69.9 58.4 44.7 - - -
72 163.6 11.6 98.8 85.0 71.3 57.5 - - 153.7 13.0 94.5 80.9 67.2 53.6 - -
67 148.9 11.5 121.6 107.9 94.1 80.3 66.6 - 139.7 12.8 119.1 103.4 89.7 76.1 62.4 -
62 136.0 11.2 136.0 136.0 117.1 103.4 89.6 75.8 128.6 12.6 128.6 128.6 108.9 95.2 81.5 67.9
3750
77 183.6 11.8 83.7 68.2 52.7 - - - 172.5 13.2 79.8 64.4 48.9 - - -
72 168.4 11.7 108.6 93.1 77.6 62.1 - - 158.0 13.0 104.4 89.0 73.5 58.1 - -
67 153.3 11.6 133.4 117.9 102.4 86.9 71.4 - 143.6 12.9 129.0 113.6 98.1 82.7 67.2 -
62 140.1 11.3 140.1 140.1 127.5 112.0 96.5 81.0 132.2 12.7 132.2 132.2 119.0 103.6 88.1 72.7
57 141.1 11.3 141.1 141.1 128.2 112.7 97.2 81.6 132.5 12.7 132.5 132.5 119.2 103.7 88.3 72.8
4375
77 188.9 12.0 91.5 74.2 57.0 - - - 177.2 13.3 89.7 70.4 53.1 - - -
72 173.3 11.8 118.3 101.1 83.9 66.6 - - 162.3 13.1 114.3 97.1 79.8 62.5 - -
67 157.7 11.7 145.2 128.0 110.7 93.5 76.2 - 147.5 13.0 138.9 123.8 106.5 89.3 72.0 -
62 144.1 11.4 144.1 144.1 137.8 120.6 103.3 86.1 135.8 12.8 135.8 135.8 129.2 112.0 94.7 77.4
57 145.2 11.4 145.2 145.2 138.6 121.3 104.1 86.8 136.1 12.8 136.1 136.1 129.4 112.1 94.8 77.6
5000
77 194.1 12.1 99.2 80.3 61.3 - - - 181.9 13.3 99.7 76.3 57.3 - - -
72 178.1 11.9 128.1 109.1 90.1 71.2 - - 166.6 13.2 124.2 105.2 86.1 67.0 - -
67 162.1 11.8 157.0 138.0 119.0 100.0 81.0 - 151.4 13.1 148.8 134.0 114.9 95.9 76.8 -
62 148.1 11.5 148.1 148.1 148.1 129.2 110.2 91.2 139.4 12.9 139.4 139.4 139.4 120.3 101.3 82.2
57 149.2 11.5 149.2 149.2 148.9 130.0 111.0 92.0 139.7 12.9 139.7 139.7 139.6 120.5 101.4 82.4
5625
72 183.1 11.9 138.0 117.4 96.9 76.4 - - 170.9 13.2 133.8 113.2 92.7 72.1 - -
67 166.6 11.8 164.0 148.5 128.0 107.4 86.9 - 155.3 13.1 154.0 143.5 123.7 103.1 82.5 -
62 152.2 11.5 152.2 152.2 152.2 131.7 111.2 90.7 143.0 12.9 143.0 143.0 143.0 122.4 101.8 81.2
57 153.4 11.5 153.4 153.4 153.2 132.7 112.2 91.6 143.3 12.9 143.3 143.3 143.2 122.6 102.0 81.5
6250
72 188.0 11.9 147.8 125.7 103.7 81.6 - - 175.1 13.2 143.4 121.3 99.2 77.1 - -
67 171.1 11.8 171.1 159.0 136.9 114.8 92.8 - 159.1 13.1 159.1 153.1 132.5 110.4 88.3 -
62 156.3 11.5 156.3 156.3 156.3 134.3 112.2 90.1 146.5 12.9 146.5 146.5 146.5 124.4 102.3 80.3
57 157.5 11.5 157.5 157.5 157.5 135.4 113.4 91.3 146.8 12.9 146.8 146.8 146.8 124.7 102.7 80.6
