246824-YTG-G-1208
26 Johnson Controls Unitary Products
ZH102 (8.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
2125
77 125.2 6.6 57.1 45.0 35.0 - - - 122.5 7.0 54.2 44.2 34.2 - - -
72 116.5 6.6 70.4 60.4 50.3 40.3 - - 112.6 7.0 69.1 59.1 49.1 39.1 - -
67 107.7 6.6 83.6 75.7 65.6 55.6 45.6 - 102.7 7.0 84.1 74.0 64.0 54.0 44.0 -
62 98.3 6.6 98.3 97.6 78.5 68.4 58.4 48.4 93.7 6.9 93.7 93.4 77.0 67.0 57.0 47.0
2550
77 130.8 6.5 62.2 50.6 39.0 - - - 127.0 7.0 61.1 49.5 37.9 - - -
72 121.6 6.5 79.3 67.7 56.1 44.5 - - 116.7 7.0 77.6 66.0 54.4 42.8 - -
67 112.5 6.5 96.4 84.8 73.2 61.6 50.0 - 106.4 7.0 94.1 82.5 70.9 59.3 47.7 -
62 102.6 6.5 102.6 102.2 87.5 75.9 64.3 52.7 97.1 6.9 97.1 96.9 85.3 73.7 62.1 50.5
57 100.7 6.5 100.7 100.7 89.3 77.7 66.1 54.5 97.1 6.9 97.1 97.1 85.7 74.1 62.5 50.9
2975
77 136.3 6.3 67.3 56.2 43.0 - - - 131.4 7.0 68.0 54.7 41.6 - - -
72 126.8 6.3 88.2 75.0 61.9 48.7 - - 120.8 7.0 86.0 72.8 59.7 46.5 - -
67 117.2 6.3 109.2 93.9 80.7 67.5 54.4 - 110.2 7.0 104.0 90.9 77.8 64.6 51.4 -
62 106.9 6.3 106.9 106.7 96.5 83.3 70.2 57.0 100.5 6.9 100.5 100.4 93.6 80.4 67.3 54.1
57 105.0 6.3 105.0 105.0 98.5 85.4 72.2 59.0 100.5 7.0 100.5 100.5 94.0 80.8 67.6 54.5
3400
77 141.9 6.2 72.4 61.8 47.0 - - - 135.9 7.0 74.9 60.0 45.3 - - -
72 131.9 6.2 97.1 82.4 67.6 52.9 - - 124.9 7.0 94.4 79.7 65.0 50.2 - -
67 121.9 6.2 121.9 103.0 88.3 73.5 58.8 - 113.9 7.0 113.9 99.4 84.6 69.9 55.2 -
62 111.2 6.2 111.2 111.2 105.5 90.8 76.0 61.3 103.9 6.9 103.9 103.9 101.9 87.1 72.4 57.7
57 109.3 6.2 109.3 109.3 107.7 93.0 78.2 63.5 103.9 7.0 103.9 103.9 102.3 87.5 72.8 58.1
3825
72 135.0 6.2 123.1 97.7 72.3 46.9 - - 127.6 7.0 111.3 90.5 69.7 48.9 - -
67 124.8 6.2 124.8 115.3 94.3 68.9 43.5 - 116.4 7.0 116.4 109.1 90.8 70.0 49.2 -
62 113.8 6.2 113.8 113.8 111.0 85.6 60.2 34.8 106.2 7.0 106.2 106.2 105.2 84.4 63.6 42.8
57 111.8 6.2 111.8 111.8 111.0 85.6 60.3 34.9 106.2 7.0 106.2 106.2 105.4 84.6 63.8 43.0
4250
72 138.1 6.2 149.0 113.0 76.9 40.9 - - 130.3 7.0 128.1 101.3 74.4 47.6 - -
67 127.6 6.2 127.6 127.6 100.4 64.3 28.3 - 118.9 7.0 118.9 118.9 97.0 70.2 43.3 -
62 116.4 6.3 116.4 116.4 116.4 80.4 44.3 8.3 108.5 7.0 108.5 108.5 108.5 81.6 54.8 27.9
57 114.4 6.2 114.4 114.4 114.4 78.3 42.3 6.2 108.5 7.0 108.5 108.5 108.5 81.6 54.8 27.9
95°F 105°F
2125
77 119.8 7.3 51.2 43.5 33.5 - - - 112.1 8.4 45.1 39.9 29.9 - - -
72 108.7 7.3 67.9 57.9 47.9 37.9 - - 101.7 8.4 64.7 54.8 44.8 34.9 - -
67 97.7 7.3 84.6 72.4 62.4 52.4 42.4 - 91.2 8.4 84.3 69.6 59.7 49.8 39.8 -
62 89.1 7.2 89.1 89.1 75.6 65.6 55.6 45.6 83.4 8.3 83.4 83.4 72.8 62.9 53.0 43.0
2550
77 123.2 7.5 60.0 48.4 36.8 - - - 114.7 8.5 55.9 44.4 33.0 - - -
72 111.8 7.5 75.8 64.3 52.7 41.1 - - 104.0 8.5 72.3 60.8 49.3 37.9 - -
67 100.4 7.5 91.7 80.2 68.6 57.0 45.5 - 93.3 8.5 88.7 77.2 65.7 54.2 42.8 -
62 91.6 7.4 91.6 91.6 83.1 71.6 60.0 48.4 85.3 8.4 85.3 85.3 80.2 68.7 57.2 45.7
57 93.5 7.4 93.5 93.5 82.0 70.4 58.8 47.3 87.0 8.5 87.0 87.0 76.8 65.3 53.8 42.3
2975
77 126.5 7.6 68.7 53.3 40.2 - - - 117.3 8.6 66.7 49.0 36.0 - - -
72 114.9 7.6 83.8 70.6 57.5 44.3 - - 106.4 8.6 79.9 66.9 53.9 40.8 - -
67 103.2 7.6 98.8 88.0 74.8 61.7 48.5 - 95.4 8.6 93.1 84.8 71.7 58.7 45.7 -
62 94.1 7.5 94.1 94.1 90.7 77.5 64.4 51.2 87.2 8.6 87.2 87.2 87.5 74.5 61.4 48.4
57 96.0 7.6 96.0 96.0 89.4 76.3 63.1 50.0 89.0 8.6 89.0 89.0 83.8 70.8 57.7 44.7
3400
77 129.9 7.8 77.5 58.2 43.5 - - - 119.9 8.7 77.6 53.6 39.0 - - -
72 117.9 7.8 91.7 77.0 62.3 47.5 - - 108.8 8.7 87.6 73.0 58.4 43.8 - -
67 105.9 7.8 105.9 95.7 81.0 66.3 51.6 - 97.6 8.7 97.6 92.3 77.8 63.2 48.6 -
62 96.6 7.7 96.6 96.6 98.2 83.5 68.7 54.0 89.2 8.7 89.2 89.2 94.8 80.2 65.6 51.0
57 98.6 7.7 98.6 98.6 96.8 82.1 67.4 52.7 91.0 8.7 91.0 91.0 90.8 76.2 61.6 47.0
3825
72 120.3 7.8 99.5 83.3 67.1 50.9 - - 110.9 8.7 95.1 79.0 63.0 46.9 - -
67 108.0 7.8 108.0 102.9 87.3 71.1 55.0 - 99.5 8.7 99.5 96.9 83.9 67.8 51.8 -
62 98.6 7.7 98.6 98.6 99.3 83.2 67.0 50.8 91.0 8.6 91.0 91.0 93.8 77.8 61.7 45.7
57 100.6 7.7 100.6 100.6 99.7 83.5 67.3 51.1 92.8 8.7 92.8 92.8 92.7 76.7 60.6 44.6
4250
72 122.6 7.8 107.2 89.6 71.9 54.3 - - 113.1 8.7 102.6 85.1 67.6 50.1 - -
67 110.1 7.8 110.1 110.1 93.6 76.0 58.3 - 101.5 8.7 101.5 101.5 90.0 72.5 55.0 -
62 100.5 7.7 100.5 100.5 100.5 82.9 65.2 47.6 92.8 8.6 92.8 92.8 92.8 75.3 57.8 40.3
57 102.5 7.7 102.5 102.5 102.5 84.9 67.3 49.6 94.6 8.7 94.6 94.6 94.6 77.1 59.6 42.2
