York PREDATOR R-410A User Manual

246824-YTG-G-1208
Johnson Controls Unitary Products 47
75°F 85°F
2500
72 59.1 8.4 0.6 0.7 0.9 - - 52.8 8.9 3.0 3.8 4.5 - -
67 53.8 8.0 -0.9 -0.7 -0.5 -0.4 - 49.1 8.4 -6.0 -5.2 -4.4 -3.6 -
62 49.1 7.6 -2.2 -2.0 -1.9 -1.7 -1.5 42.8 8.0 - - - - -
3000
72 62.5 8.1 -4.4 -5.1 -5.8 - - 56.8 8.6 -4.1 -4.4 -4.7 - -
67 56.9 7.7 5.5 4.8 4.1 3.4 - 52.7 8.1 2.3 2.0 1.7 1.4 -
62 52.0 7.4 14.7 14.0 13.3 12.6 11.9 46.1 7.8 2.8 2.4 2.1 1.8 1.5
57 50.9 7.3 17.4 16.8 16.1 15.4 14.7 45.6 7.7 2.5 2.1 1.8 1.5 1.2
3500
72 65.9 7.9 -9.4 -11.0 -12.5 - - 60.7 8.4 -11.1 -12.5 - - -
67 60.0 7.5 11.8 10.2 8.7 7.1 - 56.4 7.9 10.6 9.2 7.8 6.4 -
62 54.8 7.1 31.5 30.0 28.4 26.9 25.3 49.3 7.5 24.2 22.8 21.4 19.9 18.5
57 53.7 7.0 37.0 35.9 34.4 32.8 31.3 48.8 7.5 27.2 26.4 25.0 23.6 22.1
4000
72 69.4 7.6 - - - - - 64.7 8.1 - - - - -
67 63.1 7.2 18.1 15.7 13.3 10.9 - 60.0 7.6 18.9 16.4 13.9 11.4 -
62 57.7 6.9 48.4 46.0 43.5 41.1 38.7 52.6 7.3 45.6 43.1 40.6 38.1 35.6
57 56.5 6.8 56.5 55.1 52.7 50.3 47.9 52.0 7.2 52.0 50.6 48.1 45.6 43.1
4500
72 70.6 7.6 - - - - - 64.7 8.1 - - - - -
67 64.3 7.2 21.9 19.0 16.0 13.0 - 60.0 7.6 20.9 18.1 15.2 12.3 -
62 58.7 6.9 54.0 52.8 49.9 46.9 43.9 52.5 7.3 49.1 47.8 44.9 42.1 39.2
57 57.5 6.8 57.5 56.8 53.8 50.9 47.9 52.0 7.2 52.0 51.3 48.4 45.6 42.7
5000
72 71.9 7.6 - - - - - 64.7 8.1 - - - - -
67 65.4 7.2 25.8 22.2 18.7 15.2 - 60.1 7.6 23.0 19.8 16.5 13.3 -
62 59.7 6.9 59.7 59.7 56.2 52.7 49.2 52.5 7.3 52.5 52.5 49.2 46.0 42.8
57 58.5 6.8 58.5 58.5 55.0 51.5 47.9 52.0 7.2 52.0 52.0 48.7 45.5 42.3
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate
Blower Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
ZR120 (10 Ton) Reheat (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
85 80 75 70 65 85 80 75 70 65
