York Predator ZR series User Manual

5167540-YIM-H-0518
24 Johnson Controls Ducted Systems
Table 10: Physical Data
ZR037-061 Single Stage Gas Heat Physical Data
Component
Models
ZR037 ZR049 ZR061
Nominal Tonnage 3 4 5
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (Btu) 36500 49000 62000
AHRI net capacity (Btu) 35500 46900 58000
EER 12.2 12.1 12.1
SEER 14.7 14.5 14.25
CFM 1200 1600 2000
System power (KW) 2.88 3.32 4.83
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 11-8 11-0 11-0
System 2 - - -
AHRI HEATING PERFORMANCE
Heating model H06 H08 H12 H06 H08 H12 H08 H12 H16
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE ------
Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 4 4 6 4 4 6 4 6 8
No. stages 1 1 1 1 1 1 1 1 1
Temperature Rise Range (ºF) 20-50°F 25-65°F 50-80°F 20-50°F 25-65°F 50-80°F 25-65°F 35-65°F 45-75°F
Gas Limit Setting (ºF) 235 200 255 235 200 255 200 245 240
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4
DIMENSIONS (inches)
Length 89 89 89
Width 59 59 59
Height 42 42 42
OPERATING WT. (lbs.) 867 880 867
COMPRESSORS
1
Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.9 11.9 11.9
Rows 1 1 1
Fins per inch 23 23 23
Tube diameter (in./MM) .98/25 .98/25 .71/18 - .98/25
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 10.56 10.56 10.56
Rows 3 3 4
Fins per inch 15 15 12
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV
REHEAT COIL DATA
Face area (Sq. Ft.) 7.78 7.78 7.78
Rows 2 2 2
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control Solenoid Solenoid Solenoid
