York YCAS0200 User Manual

81YORK INTERNATIONAL
FORM 201.18-NM1 (102)
ALUMINIUM OR BLACK FIN CONDENSER COILS
WEIGHT DISTRIBUTION AND
ISOLATOR MOUNT POSITIONS
Electrical Center
A
D
CB
E
H
GF
LD03527
60 HERTZ, 2" DEFL. ISOLATOR SELECTION - VMC MODEL # AWMR-X-XXX (SEISMIC)
60 HZ A B C D E F G H
YCAS0130 1-553 1-551 1-532 1-530 1-553 1-551 1-532 1-530
YCAS0140 1-553 1-551 1-532 1-530 1-553 1-551 1-532 1-530
YCAS0150 1-552 1-552 1-532 1-531 1-553 1-552 1-551 1-532
YCAS0160 1-552 1-552 1-532 1-531 1-553 1-552 1-551 1-532
YCAS0170 1-553 1-552 1-532 1-531 1-553 1-552 1-551 1-532
YCAS0180 1-553 1-552 1-532 1-531 1-553 1-552 1-551 1-532
YCAS0200 1-551 1-552 1-552 1-553 1-551 1-552 1-552 1-553
YCAS0210 1-551 1-552 1-552 1-553 1-551 1-552 1-552 1-553
YCAS0230 1-551 1-552 1-552 1-553 1-551 1-552 1-552 1-553
7
60 HERTZ WEIGHT DISTRIBUTION BY MODEL (LBS)
60 HZ A B C D E F G H TOTAL
YCAS0130 1,956 1,633 1,309 986 1,908 1,593 1,277 962 11,625
YCAS0140 1,963 1,638 1,313 989 1,931 1,612 1,292 973 11,711
YCAS0150 1,868 1,648 1,428 1,208 1,958 1,727 1,497 1,266 12,599
YCAS0160 1,892 1,677 1,462 1,248 1,955 1,733 1,511 1,289 12,768
YCAS0170 1,903 1,689 1,475 1,261 1,982 1,759 1,536 1,313 12,919
YCAS0180 1,907 1,693 1,479 1,265 1,994 1,770 1,546 1,323 12,978
YCAS0200 1,572 1,675 1,779 1,882 1,614 1,720 1,826 1,932 13,998
YCAS0210 1,581 1,688 1,795 1,902 1,628 1,739 1,849 1,959 14,141
YCAS0230 1,583 1,689 1,795 1,901 1,637 1,746 1,855 1,965 14,171
