Page 26
4.8 DESCRIPTION OF POWER CONNECTIONS
4.8.1 "Dualac2"
View of the power bars:
-B Negative of the battery.
+BT Positive of the battery; if the power fuse is not present, the positive
cable coming from LC contact must be connected to this power
connection.
+BTF Positive of battery before power fuse, must be connected to positive
cable coming from LC contact.
Um; Vm; Wm Connection bars of the three right motors phases; follow this se-
quence and the indication on the motor.
Us; Vs; Ws Connection bars of the three left motors phases; follow this se-
quence and the indication on the motor.
