Page 55
The following table shows the different values at which the parameters can be set.
PARAMETER PROGRAMMED LEVEL
UNIT0123456789
ACCELERATION DELAY (*) Sec. 11.522.533.544.555.5
RELEASE BRAKING (**) Sec. 5.5 5 4.5 4 3.5 3 2.5 2 1.5 1
INVERSION BRAKING (**) Sec. 5.5 5 4.5 4 3.5 3 2.5 2 1.5 1
PEDAL BRAKING (**) Sec. 5.5 5 4.5 4 3.5 3 2.5 2 1.5 1
SPEED LIMIT BRAKING (**) Sec. 8.9 8.3 7.7 7.1 6.6 6.0 5.5 4.9 4.4 3.8
BRAKE CUTBACK (**) Sec. 5.5 5 4.5 4 3.5 3 2.5 2 1.5 1
MAX SPEED FW Hz 65 80 95 110 125 140 155 170 185 200
MAX SPEED BW Hz 65 80 95 110 125 140 155 170 185 200
CURVE CUTBACK % 10 15 20 25 38 50 63 75 87 100
CUTBACK SPEED % 10 15 20 25 38 50 63 75 87 100
FREQUENCY CREEP Hz 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3
MAXIMUM CURRENT % IMAX 43 50 56 62 68 75 81 87 94 100
AUXILIARY TIME Sec. 0 0.2 0.4 0.8 1 1.5 2 3 4 5
(*) The acceleration time shown is the time from 0 Hz to 100 Hz. This is the ideal ramp
calculated by the software; the real ramp could change as a function of motor control
parameter setting and, obviously, as a function of the load.
(**) The braking feature is based upon deceleration ramps. The value shown in the table
is the time to decrease the speed from 100 Hz to 0 Hz. This is the ideal ramps calcu-
lated by the software; the real ramp could change as a function of motor control pa-
rameter setting and, obviously, as a function of the load.
5.5.4 "Dualac2&hp" - Slave
Here following the list of parameters which can be set in this menu:
1 PU. ACCELER. DELAY: acceleration ramp of pump motor.
2 PU. DECELER. DELAY: deceleration ramp of pump motor.
3 SPEED LIMIT: determines the maximum lifting speed (per cent of
voltage applied to the motor) with a potentiometer
control, when the potentiometer is at the maximum of
the programmed range.
4 CREEP SPEED: determines the minimum lifting speed (per cent of
voltage applied to the motor) with a potentiometer
control, when the potentiometer is at the minimum of
the programmed range.
