AEXZP0BB - ECO SMART DISPLAY - User Manual Page - 17/43

5 DESCRIPTION OF CONNECTORS

5.1 CNA connector: Molex Minifit 6 pins

A1 -BATT Eco Smart Display negative supply.

A2 -BATT Eco Smart Display negative supply.

A3 CAN-H Can signal high.

A4 CAN-L Can low signal.

A5 FREE Not used.

A6 KEY Eco Smart Display positive power supply.
