3 INSTALLATION HINTS
In the description of these installation suggestions you will find some boxes of
different colours, they mean:
4 These are information useful for anyone is working on the installation, or a
deeper examination of the content
U These are Warning boxes, they describe:
- operations that can lead to a failure of the electronic device or can be
dangerous or harmful for the operator;
- items which are important to guarantee system performance and safety
3.1 Material overview
Before to start it is necessary to have the required material for a correct
installation. Otherwise a wrong choice of cables or other parts could lead to
failures/ misbehaviour/ bad performances.
3.1.1 Connection cables
For the auxiliary connections, use cables of 0.5-1.0 mm² section.
3.1.2 Fuses
- Use a 6.3 A Fuse for protection of the card.
- For Safety reasons, we recommend the use of protected fuses in order to
prevent the spread of fused particles should the fuse blow.
3.2 Installation of the hardware
U Before doing any operation, ensure that the battery is disconnected and
when all the installation is completed start the machine with the drive
wheels raised from the floor to ensure that any installation error do not
compromise safety.
U Do not connect the module to a battery with a nominal voltage different
than the value indicated on the label. A higher battery voltage may cause a
logic failure. A lower voltage may prevent the logic operating.
